The solution to combatting counterfeit parts? Using secret magnetic tags in 3D printing

Ensuring manufactured goods and components have not been copied and replaced illegally by counterfeited goods is a high-priority concern of the manufacturing and defence industries around the world.

A potential solution would hold wide-reaching impacts and implications in various areas, ranging from enhancing biomedical implants to protecting national defence assets.

Texas A&M University researchers have developed a method of imprinting a hidden magnetic tag, encoded with authentication information, within manufactured hardware during the part fabrication process.

The revolutionary process holds the potential to expose counterfeit goods more easily by replacing physical tags – such as barcodes or quick response (QR) codes – with these hidden magnetic tags, which serve as permanent and unique identifiers.

Ensuring security and reliable authentication in manufacturing is a critical national concern, with the US investing billions of dollars in manufacturing. Without such a method readily available, it can be nearly impossible to differentiate an authentic part or component from its counterfeit copy.

“The issue is that when I come up with an idea, device or part, it is very easy for others to copy and even fabricate it much more cheaply – though maybe at a lower quality," Ibrahim Karaman, Chevron Professor I and Department Head of the materials science and engineering department, said.

"Sometimes they even put the same brand name, so how do you make sure that item isn't yours? [The embedded magnetic tag] gives us an opportunity and a new tool to make sure that we can protect our defence and manufacturing industries."

The team is implementing metal additive manufacturing techniques to accomplish its goal of successfully embedding readable magnetic tags into metal parts without compromising on performance or longevity.

Researchers used 3D printing to embed these magnetic tags below the surface into nonmagnetic steel hardware.
Other applications for this method include traceability, quality control and more, largely depending on the industry in which it is used.

Once embedded into a nonmagnetic item, the magnetic tag is readable using a magnetic sensor device – such as a smartphone – by scanning near the correct location on the product, allowing the designated information to be accessed by the user.

While other methods exist for imprinting information, they primarily require sophisticated and costly equipment that introduces a barrier to real-world implementation.

"Different approaches have been used to try to locally change the properties of the metals during the manufacturing process to be able to codify information within the part," said Daniel Salas Mula, a Researcher with the Texas A&M Engineering Experiment Station.

"This is the first time that magnetic properties of the material are being used in this way to introduce information within a nonmagnetic part, specifically for the 3D printing of metals."

Doctoral student Deniz Ebeperi said that to map the magnetic reading of the part, the team created a custom three-axis magnetic sensor capable of mapping the surface and revealing the regions where the embedded magnetic tag was accessible.

While the system is more secure than a physical tag or code located on the exterior of an item, the team is still working to improve the complexity of the method's security.

As the project continues, Karaman said the next steps include developing a more secure method of reading the information, possibly through the implementation of a physical "dual-authentication", requiring the user to apply a specific treatment or stimulus to unlock access to the magnetic tag.
