Accurate & consistent level detection regardless of media

The appropriately named CleverLevel PL20 level switches utilise frequency sweep technology which ensures accuracy and consistency regardless of the type of process medium being measured.

The switches provide reliable limit detection without the need for parameterisation to a specific medium so, regardless of whether the process medium is liquid, paste-like, sticky, or granular, the CleverLevel PL20 recognises them reliably and securely.

Consequently, they are ideal for industrial and hygienic applications as they also distinguish foam and liquid as well as detecting separating layers.

Their ability to adjust to different process mediums saves set-up time and helps to maintain high levels of process safety. It also provides an effective solution for process media detection in pipes, reliable overfill protection of tanks, and general leakage detection. They are an ideal alternative to vibrating forks, as even the adherence of pasty materials does not affect their performance. With adhesive materials, they continue automatically to adjust the switching level without the need for parameterisation.

Other user-friendly features include a 360º LED switching state indicator which provides information about the state of the process at all times. Also, the combination of a compact design, a minimal installation depth of 15mm and self-draining sensor tip compared to a vibrating fork, simplifies installation, ensures minimal invasion in the process and helps with cleaning.

It is also approved to both 3A and EHEDG standards and can be configured visually and easily via the dedicated software and the FlexProgrammer.

Thanks to IO-Link integration, the CleverLevel switches are industry 4.0 ready with a communication interface enabling each application to be configured quickly using standard network components. This ensures error-free duplication of the system and device replacement, without the need for additional programming, thereby saving time.
