New DTI-Logger uses a single cable to transmit data from multiple sensors

DTI converts each signal into a unique, time stamped digital output either directly in the Kistler DTI sensors or via suitable Kistler DTI A/D converters connected to any existing sensors. Kistler's DTI provides a single-cable solution that greatly simplifies vehicle dynamics and durability tests; a solution to meet future challenges. SyncSwitch, the latest addition to the Kistler DTI data logger system, has substantially increased capacity to 288 channels connected by a single Ethernet cable to a computer for real time, on-site evaluation.

Kistler is the only manufacturer to partner with automobile manufacturers by offering efficient test setups that feature additional benefits such as automatic sensor detection. For OEMs with limited resources available for the necessary tests, DTI is an efficient way of speeding up processes without compromising on precision, safety and reliability.

A simple test setup that saves time and money

The new system provides users with a complete measuring chain from sensor and the DTI-Logger to the user interface with KiCenter software. Typical applications include brake path measurement with straightforward ABS braking to DIN 70028 with many advantages including: fast, simple and clear wiring automatic sensor detection easy access to installed position, calibration values and physical parameters step-by-step configuration with KiCenter PC software interference free and synchronised data transmission via the new DTI logger with Ethernet connection.

Even complex test setups require only one cable to configure the sensors, transmit and synchronise the measurement data, and provide the power supply to work efficiently and save time so test engineers can focus on the measurement tasks.
